HAPP35P

Hoist HAPP35P 4T 2 Post Floor Plate, 2.726m column, 1800mm lift

$3,490.00

GST INCLUSIVE AND COMES WITH A FIVE YEAR STRUCTURAL WARRANTY.

The best Australian Standards designs developed in Queensland for Australians, built by mostly Robots in one of the worlds most advanced factories and registered with Workplace Health and Safety.

LOW 2.726m column height for low ceiling height and high lift requirements.

The HAPP35P two post floor plate hoist, with hydraulic lift is ideal for home enthusiasts that want maximum lift height and support for those unusual sized vehicles with our GEN 2 arms but don’t have the ceiling height for the other HAPP floor plate lifts (they are typically 2.84m columns).  This lift has a 2 point manual release mechanism.  We also supply a single point release version (HAPP 70P)   For those with less that 2.726m height you can get the HAPP 95 (2.4m columns) and HAPP 90 (2.0m columns).

The Happ 35P – is the same as HAPP 30P but has 100mm shorter columns (2.726m vs 2.84m) and as such has a lower lift height (1800mm vs 1900mm).  It is also slightly narrower as 35P customers are typically looking for narrower lifts.

Available on backorder

Options

Large Base Floor Plate

GST INCLUSIVE AND INCLUDING THE BOLTS REQUIRED PLUS POSTAGE

The large base plate is exactly that… A big base plate for HAPP hoists. 2 will be sent each time.

If you are concerned about the ability of your concrete to support a Happ hoist this accessory may be the answer. The plate measures a whopping 700 x 700mm extending the contact area of the hoist by almost 4 times spreading the load over this large area.

Stabiliser Bars E4

GST INCLUSIVE PLUS POSTAGE

The HAPP E4 stabilizer bar provides extra front to back stability for HAPP hoists.

These are sold as a set of TWO.

Bundled product placeholder image

G2L Generation2 2x 2pc Long Arms

Bundled product placeholder image

G2S Generation2 2x 2pc Short Arms

Bundled product placeholder image

WH&S Kit

Bundled product placeholder image

3 Phase Full Pump Assembly Upgrade

SKU: HAPP35P Categories: , , , Tags: , , , , , , , , , , , , , , , , , , , , , , , , ,

THIS HOIST IS GST INCLUSIVE AND HAS A FIVE YEAR STRUCTURAL WARRANTY

HAPP35P 4T 2 Post Floor Plate Hoist, 2.726m column, 1800mm lift

This hoist is designed, tested  and verified to Australian standards at 4T SWL by Queensland professional engineers. The verified design is registered with WH&S for workshop use.

Some of the other features included are:

  • Over pressure limit switch inside the column to eliminate high pressure on seals
  • Removable carriage nylon blocks without removing column provides easy maintenance
  • Fully Australian Standard wiring (double insulation of limit switch wires, 4 amp fusible link on limit switch wires, industrial plug on 1m fly lead for power)
  • Screw in drop in pads with 2″ and 4″ adaptors
  • The latest Generation 2 arms and carriage designs
  • All structurally designed and analysed using the latest computer design capabilities and robot manufacturing
  • 160mmx20mm Tru bolts for maximum locking to concrete out of mechanical anchors (chemical fasteners are better if you have access to an experienced operator)
  • 5 year structural warranty , 12 month manufacturer parts warranty see happ.com.au/warranty

The screw in pad allows for ease of adjustment and the drop in style allows you to add in spacers to reach those unusual contact points. It is also a multi levelled screw in pad, giving you more height if required.  We have also included 2″ and 4″ spacers at no extra charge.

FREE low profile ramps provided with all our 2 post car hoists.

Important: EVERY HAPP car lift design is tested in Queensland by Australian Professional engineers against Australian Standards using state of the art technology!!!! The multi coloured pictures on our lift specs are snippets from the engineers report that PROVES that we are doing this. We are the leaders in quality, if you do not see this drawing on your product, it is NOT tested to Australian Standards.
Download Spec Sheet

Contact Us

About Happ HAPP is a Company created by car enthusiasts for car enthusiasts. Car clubs asked us to change the game and we did. We take our job seriously and will only offer you the best products that we can source. We have sold hoists all across Australia. Our prices are the best, with quality and service assured.


I purchased a HAPP 90 hoist off your company 12 months ago. Prior to the purchase you were very helpful in answering all my questions which made the decision to purchase easy. As I had limited height a full height hoist was not possible but your HAPP ... HAPP90 – portable 2 post – Steve Durrington – April 10, 2016


WE PURCHASED A HAPP40P TWO POST LIFT FOR USE IN MY SON'S SHED FOR OUR PERSONAL USE, VERY HAPPY WITH THE OUT COME, WE FOUND THE HAPP PEOPLE VERY HELPFUL, COULD NOT BE HAPPIER. Happ40P 2 post 4T clear floor – Cheryl Lewis, June 2021

Read More Reviews

Weight 620 kg
Dimensions 280 × 76 × 55 cm
Load Capacity

4000kgs
Lifting Height

1800mm
Overall Height

2726mm
Overall Width

3296mm
Width between pillars

2700mm
Rise/Drop time

50s rise / 20s drop time
Net weight

600kg
CE approved Hydraulic Power Pack

Yes
Motor Capacity

240V single phase
Power of motor

2.2kw
Two point safety release

Yes
Fast Dual-cylinder lifting system

Yes
Chain-driven system

Yes
Cable and hydraulic load balancing

Yes
Automatic safety locks

Yes
Cable-equalization system

Yes
Min pad height

100mm
Plastic powder coat finish

Yes
Download Spec Sheet

Contact Us

About Happ HAPP is a Company created by car enthusiasts for car enthusiasts. Car clubs asked us to change the game and we did. We take our job seriously and will only offer you the best products that we can source. We have sold hoists all across Australia. Our prices are the best, with quality and service assured.


Consider me a very happy client, and more than thrilled that I don’t have to get on my back under ramps again. HAPP35 – John Walker – August 29, 2016


Purchased the 2 post HAPP35 4T hoist and I can’t fault it. Easy installation, good quality at a great price. Highly recommend these guys. Hassle free customer service and very helpful with prompt delivery. HAPP35 – floor plate hoist – Brenton Fritz – April 3, 2016

Read More Reviews

  • We are an Australian owned and operated company with a focus on the best possible quality for reasonable prices.
  • We sell mainly by recommendation. To do this we  have personal and professional customer service;  we work with every customer to make sure they are happy with the products they purchase.
  • Imported products are typically assembled overseas to keep the costs down. We  have a Qualified Mechanical engineer working for us in China and other engineering inspection companies engaged that inspect our products and partner companies’ quality processes. Inspections typically take place early in production including internal components which are reworked if not up to standard. Critical components are focused on to ensure key products are made correctly.
  • We also use the best possible materials in our products. Our clear floor hoists have stainless steel hydraulic lines and our four post hoists have 12+mm solid steel cables tested in Australian NATA registered laboratories. Our synchronisation cables are solid steel and safety latches are billet steel.
  • We apply the best designs from our business registered hoists into our home use hoists.  For example, all arms on the two post hoists have the 4T updates, and carriages have the bracing update specified by Australian Engineers for our business hoists.
  • We offer an ever increasing range of workshop items allowing customers to source extra items at low cost, many of these items are half the cost of other suppliers – just ask us to email you our catalogue.
  • This hoist is erected in Ormeau for you to view before placing an order.
